Sunsynk HV 61.44kWh Battery Set

R 245,650.00 R 312,000.00

Taxes included. Shipping calculated at checkout.

🔋 Sunsynk HV 61.44 kWh Battery Set
Model: HV-61.44
Brand: Sunsynk
Type: High-Voltage LiFePO₄ Battery Rack System (Modular, Indoor Rack Mount)

⚡ Key Features

Massive 61.44 kWh energy capacity — ideal for large residential, commercial or off-grid installations.
High-voltage system (≈ 538-691 V nominal) enabling efficient integration with large inverters and high-power systems.
LiFePO₄ (Lithium Iron Phosphate) chemistry — high safety, long cycle life (6,000+ cycles), excellent thermal stability.
Rack-mounted modular design — 12 modules in series, space efficient and service-friendly.
Fully scalable — parallel up to multiple stacks for expanding storage capacity as required.
Built for demanding environments — wide operating temperature range from -20 °C to +55 °C, robust construction and IP20 rating.
10-year product warranty for peace of mind and long-term reliability.

📐 Specifications

Specification	Value
Model	HV-61.44
Total Energy Capacity	61.44 kWh
Nominal Voltage Range	~538 V – ~691 V
Chemistry	LiFePO₄ (LFP)
Module Configuration	12 modules in series
Max Charge/Discharge Rate	~1C / up to 100 A
Operating Temperature	-20 °C (discharge) to +55 °C (charge)
Depth of Discharge (DoD)	90% typical
Cycle Life	≥6,000 cycles @ 70% end-of-life
Rack Dimensions (W×D×H)	Approximately 589 × 590 × 2,240 mm
System Weight	~628 kg
IP Rating	IP20 (Indoor Rated)
Warranty	10 years (limited)

🏷️ Quality & Support
Sunsynk’s High-Voltage (HV) series is engineered for high-capacity energy storage demands — whether for large homes, commercial sites or off-grid systems. The HV 61.44 kWh Battery Set offers modular scalability, dependable performance and comprehensive local warranty and support.

Spec Sheet And Installation Manual
