Freedom Won 80kWh LiTE Business 80/64 Lithium Battery - 52V

Freedom Won LiTE Business 80/64 Lithium Battery - 52V

🆔 Models

Battery: Freedom Won LiTE Business 80/64 Lithium Battery - 52V

Includes

Integrated BMS with full protection suite
Aluminium indoor enclosure (IP20 rated)
Shunt Trip Circuit Breaker
USB communication cable (for PC connection)
CAN Bus termination resistor

Key Features

80kWh total energy capacity with high usable output
Compatible with 48V inverter systems (52V nominal)
High discharge capability (up to 50kW peak)
Advanced BMS with full fault protection and monitoring
Long lifespan with up to 20+ years expected service life
Built-in State of Charge display and diagnostics interface
Designed for large-scale commercial and industrial energy storage applications

Specifications

Specification	Details
Total Energy Capacity	80 kWh
Usable Energy (80% DoD)	64 kWh
Usable Energy (90% DoD)	72 kWh
Current Capacity	1600 Ah
Nominal Voltage	52V (Min: 47V / Max: 56V)
Max / Continuous Charge Current	800 A
Max / Continuous Charge Power	40 kW
Max / Continuous Discharge Current	1000 A / 800 A
Max / Continuous Discharge Power	50 kW / 40 kW
Max Recommended Inverter Size	35 kVA
Short Circuit Current	24 kA

Physical Specifications

Specification	Details
Dimensions (H×W×D)	1350 × 1015 × 370 mm
Crated Dimensions	1506 × 1186 × 568 mm
Weight	637 kg
Crated Weight	697 kg

Technical & Build

Specification	Details
DC Connection	2 × 95mm² Permopower fly leads per electrode
Enclosure	Aluminium, white coated, indoor (IP20)
Protection	Overcurrent, voltage, temperature, weak cell detection, SoC control
Circuit Breaker	Shunt trip with BMS integration
Control Interface	USB Serial + RJ45 (BMS & inverter comms)
User Interface	SOC display, error indicator, reset button

Additional Requirements

CAN Bus cable (RJ45 LAN) – required (not included)
Some inverters may require custom communication cable
Installation per manufacturer guidelines recommended

Quality & Support

Engineered for high-capacity energy storage, the Freedom Won LiTE Business 80/64 delivers exceptional performance, durability, and advanced protection, making it ideal for large commercial and industrial power systems requiring dependable long-term operation.
