R 20,500.00 R 22,000.00

Taxes included. Shipping calculated at checkout.

⚡ Deye 8kW Hybrid Inverter 1-Phase Low Voltage (3rd Generation)

Model: SUN-8K-SG06LP1-EU-CM3
Brand: Deye
Type: Single-Phase Low-Voltage Hybrid Solar Inverter (3rd Generation)

⚡ Key Features

8kW single-phase hybrid inverter designed for residential and light commercial solar, battery backup, and off-grid applications.
Supports low-voltage 48V lithium-ion and lead-acid battery systems.
High-efficiency hybrid operation with up to 97.6% maximum efficiency and over 99% MPPT efficiency.
Supports AC coupling for upgrading existing grid-tied solar systems with battery storage.
Maximum battery charge/discharge current of 185A for rapid charging and reliable backup performance.
Three independent MPPT trackers maximize solar production across multiple roof orientations.
Supports up to 16,000W of PV input power for oversized solar arrays and improved energy harvesting.
Intelligent energy management with 6 programmable battery charging and discharging time periods.
Compatible with diesel generators for battery charging and backup operation.
Parallel operation of up to 16 inverters for expanded on-grid and off-grid systems.
Colour touch LCD display for intuitive system monitoring and configuration.
Built-in Wi-Fi, CAN, and RS485 communication for remote monitoring and seamless battery integration.
IP65-rated enclosure suitable for indoor and outdoor installations.
Intelligent air cooling delivers quiet and efficient operation.
Comprehensive built-in protection including anti-islanding, overvoltage, overcurrent, short-circuit, thermal protection, insulation monitoring, and Type II AC/DC surge protection.

📐 Specifications

Specification	Value
Rated Output Power	8,000 W
Battery Voltage	40–60 V
Battery Type	Lithium-ion / Lead-acid
Maximum Charge/Discharge Current	185 A
Number of Battery Inputs	1
Maximum PV Input Power	16,000 W
Maximum DC Input Power	12,800 W
MPPT Trackers	3
PV Strings	2 + 1 + 1
Maximum DC Voltage	500 V
MPPT Voltage Range	150–425 V
Start-up Voltage	125 V
Rated DC Voltage	370 V
Maximum PV Input Current	36 A + 18 A + 18 A
Maximum Short-Circuit Current	54 A + 27 A + 27 A
Rated AC Output Power	8,000 W
Maximum AC Apparent Power	8,800 VA
Rated AC Voltage	220 / 230 V
Grid Frequency	50 / 60 Hz
Maximum Efficiency	97.6%
Euro Efficiency	96.5%
MPPT Efficiency	>99%

📏 Physical Specifications

Specification	Details
Dimensions (W × H × D)	340 × 580 × 234 mm
Weight	Approximately 24.6 kg
Protection Rating	IP65
Cooling	Intelligent Air Cooling
Noise Level	<45 dB

🔧 Technical & Build

Specification	Details
Inverter Type	Single-Phase Hybrid Inverter
Battery Compatibility	48V Lithium-ion & Lead-acid
AC Coupling	Supported
Parallel Operation	Up to 16 Units
Battery Communication	CAN / RS485
Remote Monitoring	Wi-Fi
Display	Colour Touch LCD
Cooling	Intelligent Air Cooling
Operating Temperature	-40°C to +60°C (Derating Above 45°C)
Maximum Altitude	3000 m
Humidity	0–100% RH
Protection	DC Reverse Polarity, Overcurrent, Overvoltage, Short Circuit, Thermal Protection, Anti-Islanding, Type II AC/DC Surge Protection

ℹ️ Additional Information

The Deye SUN-8K-SG06LP1-EU-CM3 is a third-generation low-voltage hybrid inverter engineered for high-performance residential and light commercial energy storage systems. Featuring three MPPT trackers, high battery charging capability, and intelligent energy management, it optimizes solar generation while seamlessly managing power from solar panels, batteries, the utility grid, and optional diesel generators.

Its support for AC coupling, parallel operation of up to 16 units, and advanced battery communication makes it an excellent solution for new solar installations, battery retrofits, backup power, and off-grid applications.

🏷️ Quality & Support

The Deye 8kW Hybrid Inverter 1-Phase Low Voltage (3rd Generation) delivers exceptional efficiency, intelligent battery management, and outstanding flexibility for modern solar energy systems. Designed for seamless integration with Deye low-voltage batteries and other compatible lithium battery brands, it provides dependable long-term performance backed by Deye's comprehensive manufacturer warranty.

DATASHEET
