Canadian Solar 615W N-Type Bi-Facial Panel (Pallet)

R 66,145.00 R 70,187.00

Taxes included. Shipping calculated at checkout.

🌞 Canadian Solar 615W N-Type Bi-Facial Panel

Model: CS6.2-66TB-615H (TOPBiHiKu6 Series)
Brand: Canadian Solar

⚡ Key Features

High Power Output
Delivers up to 615 W front-side power with module efficiency up to 22.8%, providing outstanding energy generation and system performance.

Bifacial Technology
Generates additional power from the back side—up to 20% bifacial gain for a total effective power output exceeding 730 W under optimal conditions.

N-Type TOPCon Cells
Next-generation N-Type cells provide superior efficiency, reduced degradation, and enhanced long-term stability compared to P-Type technologies.

Durable Double-Glass Design
Robust dual-glass construction improves mechanical strength, weather resistance, and fire safety for long-lasting reliability.

High Reliability & Stability
Excellent anti-LeTID and anti-PID performance, minimizing power loss over the system lifetime.

Optimized for Hot Climates
Low temperature coefficient (Pmax ≈ −0.29%/°C) ensures better performance in high-temperature environments.

🧾 Technical Specifications

Specification	Value
Model	CS6.2-66TB-615H
Rated Power	615 W
Module Efficiency	Up to 22.8 %
Cell Type	N-Type TOPCon
Technology	Bifacial, Double Glass
Bifacial Gain	Up to 85 % (≈ 738 W effective)
Temperature Coefficient (Pmax)	−0.29 % / °C
Operating Temperature	−40 °C to +85 °C
Dimensions	2384 × 1303 × 35 mm
Weight	31.4 kg
Mechanical Load	Snow: 5400 Pa / Wind: 2400 Pa
Certifications	IEC 61215 / IEC 61730 / UL 61730 / IEC 61701 / IEC 62716
Warranty	12-year product / 30-year linear power output
Max System Voltage	1500 V (IEC)
Frame	Anodized Aluminum Alloy
Front Glass	3.2 mm Tempered Glass
Junction Box	IP68, 3 Bypass Diodes
Connector Type	MC4-EVO2 or Equivalent
